FFS Airbus A320-200 (FT43)

Full-Flight Simulator

AIRBUS A320-200 (FT43)

With our full-flight simulators we offer you a flight training that meets the latest technical standard and is tailor-made for the requirements of modern airlines. Naturally we adapt our simulators so that they reflect your fleet‘s systems environments and cockpit layouts as well as your airline‘s procedures. This enables you to orient your training to accord with your own line operations.

Download Product Sheet (PDF)

Specifications

Location

Lufthansa Aviation Training, Berlin-Schoenefeld

Simulator-ID

FT-43

Simulator

Simulator Manufacturer

CAE, Canada

In Service Date

August 2002

Aircraft Model

A320-212 / A320-232

Registration (Master Aircraft)

D-AICI

Product No.

L322

Simulator Host Computer

IBM Netfinity M20

Motion System

Series 600, 6 DOF, digital

Control Loading

digital, hydraulic

Aircraft System

Engine Version
Primary Fit

General Electric CFM56-5A3, 26500 lbs T/O thrust

Secondary Fit

IAE V2527-A5, 27000 lbs T/O thrust

Aerodynamic Data Revision

D00500302 and D00503300 Aerodynamic Specification for FFS

Auto Flight System
FMGS

Thales FMS2 rehosted

FCU

Sextant Std M11

FAC

CR102 (Software simulation)

MCDU

Thales (Orig. a/c boxes)

Electronic Flight Control System
ELAC

sEFCS rhosted / L91

SEC

sEFCS rhosted / L112

FCDC

sEFCS rhosted / 56

DMC

Orig. a/c box installed, EIS1 V60

FWC

Orig. a/c box installed, H2-F7

TCAS II

CAE Software Simulation, 7.1

ACARS

Orig. a/c box installed, ATSU

EGPWS

Orig. a/c box installed

ADIRS

CAE Software Simulation

MMR (hosts GPS)

CAE Software Simulation

Visual

Visual System Manufacturer

Evans & Sutherland

Type of Image Generator

EP-1000CT

Type of Display

ESP200 180x40 deg FOV mirror

Illumination Levels

Day/Dusk/Night

Number of Airport Scenes

more than 70 on request available

INSTRUCTOR STATION

Display

2x15" LCD touch screens mounted on IOS seat (FFIOS)

Printer/Plotter

Monochrome Laser Printer

Number of Malfunctions

334

Automated Training Lessons

available on request for Base Check, Conversion, LOFT, Refresher

Landing Training

Individual definition of a generic airfield (RWY Characteristics :

Length, Width, parallel RWY; RWY Lights: VLA, Appr. Lights)

Multiple Weather Simulation

Provides setting of individual weather conditions at all different airports available

Unusual Attitude Recovery Training

available

Non-Predictive Windshear Scenarios

various windshear profiles for T/O and Landing available

TCAS

various scenarios with individual definition of intruder trajectory available

ATIS

available

ACARS Scenarios

various datalink applications

customized datalink applications available on request

FMS Flight Plan Copy / Load

copy of entered flight plans and manual load of predefined flight plans

Debrief Station/Video/Recording

Color camera and SVHS Video Recorder

Display Options

metric and/or imperial

Options

10 different Customer Options available.

Up to 20 different FMS NAV databases loadable and selectable for different Customers.

QUALIFICATIONS

German LBA

JAA Level D, annually, according to JAR-STD 1A

EASA-ID

DE-1A-040
